W-PD2 Expert Dissolved Gas Monitoring System
We should have a correct understanding of the transformer faults of the power system, a large number of practical application effect that the fault in transformer oil gas, real-time monitoring of transformer fault early prevention is the most effective means. W-PD2G series of oil gas sensor fault with the more high-end series, gas composition detection configuration up to eight components. Can precisely and efficiently analyze 8 multicomponent gas. The system can continuous, online, fast automatic analysis of gases dissolved in transformer oil content and growth rate, and through the fault diagnosis expert system of transformer faults, automatic diagnosis, it is a kind of high reliability of the on-line monitoring equipment. Its application to the timely discovery transformer internal fault, avoid accidents have very important sense, extreme users online to capture transformer potential failure:
• Safety optimization to maximize output transformer.
• Estimated transformer service life.
• From the monitoring results classification fault type.
• Completely from upwards of extraction
• Based on the osmosis membrane extraction technology
• The high permeability and high temperature resistant sex film
• In the extremely low temperatures to fast, reliable extraction
• No consumption
• At least the precision requirement of the manufacturing calibration
• No deviation stability measurement
• Measurement range and laboratory DGA analysis are in agreement
• All gas without mutual interference in the conditions were measured
• From the effect of water content and admitting that the measurements
• Measuring H2, CO, CH4, C2H4, C2H2, C2H6, CO2, O2 and H2O, total hydrocarbon
