| Model |
SRI |
| Equipment use environment |
Environmental temperature-10 ~ 40 degrees Celsius |
| SF6 compressor |
category |
No oil closed |
| Theory displacement (m3 / h) |
20 |
| The highest pressure (bar) |
38 |
| Power (kW) |
15 |
| Vacuum compresso |
Pumping speed (m3 / h) |
10 |
| Inspiratory pressure (absolute pressure kPa) |
0.1 |
| Power (kW) |
0.4 |
| Vacuum pump |
Lashing velocity (L/s) |
25 |
| Limit vacuum (Pa) |
≤6×10-2 |
| Power (kW) |
3.7 |
| Vacuum plan |
Pirani digital vacuum plan |
| Device recovery eventually pressure (kPa)> |
≤60 |
| Device limit vacuum (Pa) |
≤10 |
| Vacuum keep from 133 Pa the increase in 24 hours (Pa) |
≤400 |
| Leakage rate/year |
≤1% |
| SF6 gas purity is recycled |
Water (PPM/V) |
≤60 |
| Storage containers |
Storage |
liquid |
| |
Pressure (Bar) |
39 |
| |
Volume (L) |
350 |
| |
The fluid amount (kg) |
350 |
| Liquefaction way |
High pressure |
| Dry filter regenerative way |
Vacuum heating activate |
| power |
Three-phase 380 V / 50 Hz ac |
| Total power (kW) |
≤20 |
| Noise dB (A) |
≤75 |
| Size (mm) |
1920×1080×1600 |
| Weight (kg) |
＜900 |
